Артикул: 013G7722
В наличии
Danfoss 013G7722 - Radiator Valves, RA-DV, Dynamic (pressure independent), DN 10, Straight, D
Цена по запросу Стоимость зависит от выбранного способа оплаты и количества товара.
Не отвечаем 5 минут — скидка на весь заказ!
Нужна скидка? Звони — сделаем лучшее предложение
Работаем по всей России
Возможны самовывоз и доставка по всей территории России
Надежность
Профессиональная поддержка
Danfoss 013G7722 - Radiator Valves, RA-DV, Dynamic (pressure independent), DN 10, Straight, D
Dynamic valve, pressure independent
Информация о продукте
| Gross weight | 0.27 kg |
| Net weight | 0.27 kg |
| EAN | 5702425093425 |
| Gross weight | 0.27 kg |
| Net weight | 0.27 kg |
| EAN | 5702425093425 |
| Application | 2-pipe system |
| Connection size in | Rp 3/8 |
| Connection size out | R 3/8 |
| Connection types | Internal thread |
| Description | Dynamic valve, pressure independent |
| Design | Straight |
| Differential pressure range [bar] [Max] | 0.6 bar |
| Differential pressure range [bar] [Min] | 0.1 bar |
| Dimension standard | D |
| Flow [l/h] [Max] | 135 L/h |
| Flow at setting 1 [l/h] [Max] | 10 L/h |
| Flow at setting 2 [l/h] [Max] | 15 L/h |
| Flow at setting 3 [l/h] [Max] | 20 L/h |
| Flow at setting 4 [l/h] [Max] | 35 L/h |
| Flow at setting 5 [l/h] [Max] | 50 L/h |
| Flow at setting 6 [l/h] [Max] | 80 L/h |
| Flow at setting 7 [l/h] [Max] | 100 L/h |
| Flow at setting N [l/h] [Max] | 135 L/h |
| Flow temperature [°C] [Max] | 95 °C |
| Presetting | yes |
| Product group | Radiator Valves |
| Tailpiece type | Standard |
| Test pressure [bar] | 16 bar |
| Type | RA-DV |
| Valve size | DN 10 |
| Valve type | Dynamic (pressure independent) |
| Working pressure [bar] [Max] | 10 bar |
| Application | 2-pipe system |
| Connection size in | Rp 3/8 |
| Connection size out | R 3/8 |
| Connection types | Internal thread |
| Description | Dynamic valve, pressure independent |
| Design | Straight |
| Differential pressure range [bar] [Max] | 0.6 bar |
| Differential pressure range [bar] [Min] | 0.1 bar |
| Dimension standard | D |
| Flow [l/h] [Max] | 135 L/h |
| Flow at setting 1 [l/h] [Max] | 10 L/h |
| Flow at setting 2 [l/h] [Max] | 15 L/h |
| Flow at setting 3 [l/h] [Max] | 20 L/h |
| Flow at setting 4 [l/h] [Max] | 35 L/h |
| Flow at setting 5 [l/h] [Max] | 50 L/h |
| Flow at setting 6 [l/h] [Max] | 80 L/h |
| Flow at setting 7 [l/h] [Max] | 100 L/h |
| Flow at setting N [l/h] [Max] | 135 L/h |
| Flow temperature [°C] [Max] | 95 °C |
| Presetting | yes |
| Product group | Radiator Valves |
| Tailpiece type | Standard |
| Test pressure [bar] | 16 bar |
| Type | RA-DV |
| Valve size | DN 10 |
| Valve type | Dynamic (pressure independent) |
| Working pressure [bar] [Max] | 10 bar |
Сайт продавца продукции Danfoss. Получить дополнительную информацию о стоимости, описании, спецификации и характеристиках вы можете по телефону +7 495 266-67-99 или электронной почте sale@df-russia.ru.
Технические характеристики 013G7722
Основные характеристики
- Application
- 2-pipe system
- Connection size in
- Rp 3/8
- Connection size out
- R 3/8
- Connection types
- Internal thread
- Description
- Dynamic valve, pressure independent
- Design
- Straight
- Differential pressure range [bar] [Max]
- 0.6 bar
- Differential pressure range [bar] [Min]
- 0.1 bar
- Dimension standard
- D
- EAN
- 5702425093425
- Flow at setting 1 [l/h] [Max]
- 10 L/h
- Flow at setting 2 [l/h] [Max]
- 15 L/h
- Flow at setting 3 [l/h] [Max]
- 20 L/h
- Flow at setting 4 [l/h] [Max]
- 35 L/h
- Flow at setting 5 [l/h] [Max]
- 50 L/h
- Flow at setting 6 [l/h] [Max]
- 80 L/h
- Flow at setting 7 [l/h] [Max]
- 100 L/h
- Flow at setting N [l/h] [Max]
- 135 L/h
- Flow temperature [°C] [Max]
- 95 °C
- Flow [l/h] [Max]
- 135 L/h
- Gross weight
- 0.27 kg
- Net weight
- 0.27 kg
- Presetting
- yes
- Product group
- Radiator Valves
- Tailpiece type
- Standard
- Test pressure [bar]
- 16 bar
- TYPE
- RA-DV
- Valve size
- DN 10
- Valve type
- Dynamic (pressure independent)
- Working pressure [bar] [Max]
- 10 bar
