Danfoss 060-117191 - Pressure switch, KP5
Regulation range [bar] Pe: 8.00 - 32.00, Differential [bar]: 1.80 - 6.00, Reset function: Auto, Pressure connection type: Flare, Pressure connection size: 1/4, Enclosure rating IP: IP44, Max. Working Pressure [bar]: 35.0
Информация о продукте
| Gross weight | 0.34 kg |
| Net weight | 0.3 kg |
| EAN | 5702424497675 |
| Gross weight | 0.34 kg |
| Net weight | 0.3 kg |
| EAN | 5702424497675 |
| Amb. Temp. Note | 80 °C/176 °F for max 120 min |
| Ambient temperature range [°C] [Max] | 65 °C |
| Ambient temperature range [°C] [Min] | -40 °C |
| Ambient temperature range [°F] [Max] | 149 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | BV, CCC, CE, DNV, GL, LR, LVD, PZH, RINA, RMRS, RoHS China, c UL us UL873, CS C22.2 |
| Contact function | SPDT |
| Contact rating | AC15=10 A, 400 V, AC1=16 A, 400 V, AC3=16 A, 400 V, DC13=12 W, 220 V, LR=112 A, 400 V |
| Differential [bar] [Max] | 6 bar |
| Differential [bar] [Min] | 1.8 bar |
| Differential [psi] [Max] | 87 psi |
| Differential [psi] [Min] | 26 psi |
| Electrical connection | Rubber cable gland |
| Electrical connection size | 6-14 mm |
| EN 60947 electrical properties | Pollution degree: 3, Rated impulse voltage: 4 kV |
| EN 60947 wiring properties | Flex, ferrules: 0.5-1.5 mm2, Flex, no ferrules: 0.7-2.5 mm2, Solid/stranded: 0.75-2.5 mm2 |
| Enclosure rating IP | IP44 |
| Enclosure rating Nema (~) | 2 |
| Equipment | |
| Lubricants compatibility | Oilfree applications |
| Max. test pressure [bar] Pe | 35 bar |
| Max. test pressure [psig] | 510 psig |
| Max. Working Pressure [bar] | 35 bar |
| Max. Working Pressure [psig] | 510 psig |
| Oil free refrigerants | R134a, R513A, R515B |
| Packing format | Multi pack |
| Pressure connection size | 1/4 |
| Pressure connection standard | DIN 8906 |
| Pressure connection type | Flare |
| Pressure Male/Female | Male |
| Pressure range category | High pressure |
| Pressure sensing element | Bellows |
| Product accessories | Switches accessories |
| Product description | Pressure Switch |
| Product family name | KP |
| Product group | Switches and thermostats |
| Product name | Pressure switch |
| Quantity per packing format | 36 pc |
| Refrigerant oil compatibility | Oilfree applications, R134a, R513A, R515B |
| Refrigerants | R113, R124, R134a, R22, R404A, R407A, R407C, R407F, R407H, R422B, R422D, R438A, R448A, R449A, R450A, R452A, R507A, R513A, R449B, R515B |
| Regulation range [bar] Pe [Max] | 32 bar |
| Regulation range [bar] Pe [Min] | 8 bar |
| Regulation range [psig] Pe [Max] | 464 psig |
| Regulation range [psig] Pe [Min] | 116 psig |
| Reset function | Auto |
| Serviceable | No |
| Type | KP5 |
| UL approval file name | E31024 |
| UL approved refrigerants | R113, R124, R134a, R22, R404A, R407A, R407C, R407F, R407H, R422B, R422D, R438A, R448A, R449A, R449B, R450A, R452A, R507A, R513A, R515B |
| Amb. Temp. Note | 80 °C/176 °F for max 120 min |
| Ambient temperature range [°C] [Max] | 65 °C |
| Ambient temperature range [°C] [Min] | -40 °C |
| Ambient temperature range [°F] [Max] | 149 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | BV, CCC, CE, DNV, GL, LR, LVD, PZH, RINA, RMRS, RoHS China, c UL us UL873, CS C22.2 |
| Contact function | SPDT |
| Contact rating | AC15=10 A, 400 V, AC1=16 A, 400 V, AC3=16 A, 400 V, DC13=12 W, 220 V, LR=112 A, 400 V |
| Differential [bar] [Max] | 6 bar |
| Differential [bar] [Min] | 1.8 bar |
| Differential [psi] [Max] | 87 psi |
| Differential [psi] [Min] | 26 psi |
| Electrical connection | Rubber cable gland |
| Electrical connection size | 6-14 mm |
| EN 60947 electrical properties | Pollution degree: 3, Rated impulse voltage: 4 kV |
| EN 60947 wiring properties | Flex, ferrules: 0.5-1.5 mm2, Flex, no ferrules: 0.7-2.5 mm2, Solid/stranded: 0.75-2.5 mm2 |
| Enclosure rating IP | IP44 |
| Enclosure rating Nema (~) | 2 |
| Equipment | |
| Lubricants compatibility | Oilfree applications |
| Max. test pressure [bar] Pe | 35 bar |
| Max. test pressure [psig] | 510 psig |
| Max. Working Pressure [bar] | 35 bar |
| Max. Working Pressure [psig] | 510 psig |
| Oil free refrigerants | R134a, R513A, R515B |
| Packing format | Multi pack |
| Pressure connection size | 1/4 |
| Pressure connection standard | DIN 8906 |
| Pressure connection type | Flare |
| Pressure Male/Female | Male |
| Pressure range category | High pressure |
| Pressure sensing element | Bellows |
| Product accessories | Switches accessories |
| Product description | Pressure Switch |
| Product family name | KP |
| Product group | Switches and thermostats |
| Product name | Pressure switch |
| Quantity per packing format | 36 pc |
| Refrigerant oil compatibility | Oilfree applications, R134a, R513A, R515B |
| Refrigerants | R113, R124, R134a, R22, R404A, R407A, R407C, R407F, R407H, R422B, R422D, R438A, R448A, R449A, R450A, R452A, R507A, R513A, R449B, R515B |
| Regulation range [bar] Pe [Max] | 32 bar |
| Regulation range [bar] Pe [Min] | 8 bar |
| Regulation range [psig] Pe [Max] | 464 psig |
| Regulation range [psig] Pe [Min] | 116 psig |
| Reset function | Auto |
| Serviceable | No |
| Type | KP5 |
| UL approval file name | E31024 |
| UL approved refrigerants | R113, R124, R134a, R22, R404A, R407A, R407C, R407F, R407H, R422B, R422D, R438A, R448A, R449A, R449B, R450A, R452A, R507A, R513A, R515B |
Сайт продавца продукции Danfoss. Получить дополнительную информацию о стоимости, описании, спецификации и характеристиках вы можете по телефону +7 495 266-67-99 или электронной почте sale@df-russia.ru.
Технические характеристики 060-117191
Основные характеристики
- Amb. Temp. Note
- 80 °C/176 °F for max 120 min
- Ambient temperature range [°C] [Max]
- 65 °C
- Ambient temperature range [°C] [Min]
- -40 °C
- Ambient temperature range [°F] [Max]
- 149 °F
- Ambient temperature range [°F] [Min]
- -40 °F
- Approval
- BVCCCCEDNVGLLRLVDPZHRINARMRSRoHS Chinac UL us UL873, CS C22.2
- Contact function
- SPDT
- Contact rating
- AC15=10 A, 400 VAC1=16 A, 400 VAC3=16 A, 400 VDC13=12 W, 220 VLR=112 A, 400 V
- Differential [bar] [Max]
- 6 bar
- Differential [bar] [Min]
- 1.8 bar
- Differential [psi] [Max]
- 87 psi
- Differential [psi] [Min]
- 26 psi
- EAN
- 5702424497675
- Electrical connection
- Rubber cable gland
- Electrical connection size
- 6-14 mm
- EN 60947 electrical properties
- Pollution degree: 3Rated impulse voltage: 4 kV
- EN 60947 wiring properties
- Flex, ferrules: 0.5-1.5 mm2Flex, no ferrules: 0.7-2.5 mm2Solid/stranded: 0.75-2.5 mm2
- Enclosure rating IP
- IP44
- Enclosure rating Nema (~)
- 2
- Gross weight
- 0.34 kg
- Lubricants compatibility
- Oilfree applications
- Max. test pressure [bar] Pe
- 35 bar
- Max. test pressure [psig]
- 510 psig
- Max. Working Pressure [bar]
- 35 bar
- Max. Working Pressure [psig]
- 510 psig
- Net weight
- 0.3 kg
- Oil free refrigerants
- R134aR513AR515B
- Packing format
- Multi pack
- Pressure connection size
- 1/4
- Pressure connection standard
- DIN 8906
- Pressure connection type
- Flare
- Pressure Male/Female
- Male
- Pressure range category
- High pressure
- Pressure sensing element
- Bellows
- Product accessories
- Switches accessories
- Product description
- Pressure Switch
- Product family name
- KP
- Product group
- Switches and thermostats
- Product name
- Pressure switch
- Quantity per packing format
- 36 pc
- Refrigerant oil compatibility
- Oilfree applicationsR134aR513AR515B
- Refrigerants
- R113R124R134aR22R404AR407AR407CR407FR407HR422BR422DR438AR448AR449AR450AR452AR507AR513AR449BR515B
- Regulation range [bar] Pe [Max]
- 32 bar
- Regulation range [bar] Pe [Min]
- 8 bar
- Regulation range [psig] Pe [Max]
- 464 psig
- Regulation range [psig] Pe [Min]
- 116 psig
- Reset function
- Auto
- Serviceable
- No
- TYPE
- KP5
- UL approval file name
- E31024
- UL approved refrigerants
- R113R124R134aR22R404AR407AR407CR407FR407HR422BR422DR438AR448AR449AR449BR450AR452AR507AR513AR515B
