Артикул: 060-214691
В наличии
Danfoss 060-214691 - Pressure switch, KP37
Цена по запросу Стоимость зависит от выбранного способа оплаты и количества товара.
Не отвечаем 5 минут — скидка на весь заказ!
Нужна скидка? Звони — сделаем лучшее предложение
Работаем по всей России
Возможны самовывоз и доставка по всей территории России
Надежность
Профессиональная поддержка
Danfoss 060-214691 - Pressure switch, KP37
Regulation range [bar] Pe: 4.00 - 21.00, Differential [bar]: 1.80 - 3.00, Reset function: Auto, Pressure connection type: NPT, Pressure connection size: 1/4-18, Enclosure rating IP: IP30, Max. Working Pressure [bar]: 28.0
Информация о продукте
| Gross weight | 0.38 kg |
| Net weight | 0.35 kg |
| EAN | 5702424497408 |
| Gross weight | 0.38 kg |
| Net weight | 0.35 kg |
| EAN | 5702424497408 |
| Ambient temperature range [°C] [Max] | 65 °C |
| Ambient temperature range [°C] [Min] | -40 °C |
| Ambient temperature range [°F] [Max] | 149 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | CCC, CE, EAC, FM, LVD, PZH, RINA, RMRS, RoHS China, c UL us UL353, CS C22.2, c UL us UL873, CS C22.2, LLC CDC EURO-TYSK |
| Contact function | SPDT |
| Contact rating | 120Vac,16FLA,96LRA,3APilotDuty, 16 A resistive, single phase, 240 V ac, 8 FLA, 48 LRA, 8 A resistive, single phase, 240V dc,12W pilot duty(0.05 A) |
| Differential [bar] [Max] | 3 bar |
| Differential [bar] [Min] | 1.8 bar |
| Differential [psi] [Max] | 44 psi |
| Differential [psi] [Min] | 26 psi |
| Electrical conn. Male/Female | Female |
| Enclosure rating IP | IP30 |
| Enclosure rating Nema (~) | 1 |
| Equipment | |
| Max. test pressure [bar] Pe | 32 bar |
| Max. test pressure [psig] | 464 psig |
| Max. Working Pressure [bar] | 28 bar |
| Max. Working Pressure [psig] | 405 psig |
| Packing format | Multi pack |
| Pressure connection size | 1/4-18 |
| Pressure connection standard | ANSI/ASME B1.20.1 |
| Pressure connection type | NPT |
| Pressure Male/Female | Female |
| Pressure sensing element | Bellows |
| Product accessories | Switches accessories |
| Product description | Pressure Switch |
| Product family name | KP |
| Product group | Switches and thermostats |
| Product name | Pressure switch |
| Quantity per packing format | 36 pc |
| Regulation range [bar] Pe [Max] | 21 bar |
| Regulation range [bar] Pe [Min] | 4 bar |
| Regulation range [psig] Pe [Max] | 300 psig |
| Regulation range [psig] Pe [Min] | 58 psig |
| Reset function | Auto |
| Serviceable | No |
| Type | KP37 |
| UL approval file name | E31024, MH27572 |
| Ambient temperature range [°C] [Max] | 65 °C |
| Ambient temperature range [°C] [Min] | -40 °C |
| Ambient temperature range [°F] [Max] | 149 °F |
| Ambient temperature range [°F] [Min] | -40 °F |
| Approval | CCC, CE, EAC, FM, LVD, PZH, RINA, RMRS, RoHS China, c UL us UL353, CS C22.2, c UL us UL873, CS C22.2, LLC CDC EURO-TYSK |
| Contact function | SPDT |
| Contact rating | 120Vac,16FLA,96LRA,3APilotDuty, 16 A resistive, single phase, 240 V ac, 8 FLA, 48 LRA, 8 A resistive, single phase, 240V dc,12W pilot duty(0.05 A) |
| Differential [bar] [Max] | 3 bar |
| Differential [bar] [Min] | 1.8 bar |
| Differential [psi] [Max] | 44 psi |
| Differential [psi] [Min] | 26 psi |
| Electrical conn. Male/Female | Female |
| Enclosure rating IP | IP30 |
| Enclosure rating Nema (~) | 1 |
| Equipment | |
| Max. test pressure [bar] Pe | 32 bar |
| Max. test pressure [psig] | 464 psig |
| Max. Working Pressure [bar] | 28 bar |
| Max. Working Pressure [psig] | 405 psig |
| Packing format | Multi pack |
| Pressure connection size | 1/4-18 |
| Pressure connection standard | ANSI/ASME B1.20.1 |
| Pressure connection type | NPT |
| Pressure Male/Female | Female |
| Pressure sensing element | Bellows |
| Product accessories | Switches accessories |
| Product description | Pressure Switch |
| Product family name | KP |
| Product group | Switches and thermostats |
| Product name | Pressure switch |
| Quantity per packing format | 36 pc |
| Regulation range [bar] Pe [Max] | 21 bar |
| Regulation range [bar] Pe [Min] | 4 bar |
| Regulation range [psig] Pe [Max] | 300 psig |
| Regulation range [psig] Pe [Min] | 58 psig |
| Reset function | Auto |
| Serviceable | No |
| Type | KP37 |
| UL approval file name | E31024, MH27572 |
Сайт продавца продукции Danfoss. Получить дополнительную информацию о стоимости, описании, спецификации и характеристиках вы можете по телефону +7 495 266-67-99 или электронной почте sale@df-russia.ru.
Технические характеристики 060-214691
Основные характеристики
- Ambient temperature range [°C] [Max]
- 65 °C
- Ambient temperature range [°C] [Min]
- -40 °C
- Ambient temperature range [°F] [Max]
- 149 °F
- Ambient temperature range [°F] [Min]
- -40 °F
- Approval
- CCCCEEACFMLVDPZHRINARMRSRoHS Chinac UL us UL353, CS C22.2c UL us UL873, CS C22.2LLC CDC EURO-TYSK
- Contact function
- SPDT
- Contact rating
- 120Vac,16FLA,96LRA,3APilotDuty16 A resistive, single phase240 V ac, 8 FLA, 48 LRA8 A resistive, single phase240V dc,12W pilot duty(0.05 A)
- Differential [bar] [Max]
- 3 bar
- Differential [bar] [Min]
- 1.8 bar
- Differential [psi] [Max]
- 44 psi
- Differential [psi] [Min]
- 26 psi
- EAN
- 5702424497408
- Electrical conn. Male/Female
- Female
- Enclosure rating IP
- IP30
- Enclosure rating Nema (~)
- 1
- Gross weight
- 0.38 kg
- Max. test pressure [bar] Pe
- 32 bar
- Max. test pressure [psig]
- 464 psig
- Max. Working Pressure [bar]
- 28 bar
- Max. Working Pressure [psig]
- 405 psig
- Net weight
- 0.35 kg
- Packing format
- Multi pack
- Pressure connection size
- 1/4-18
- Pressure connection standard
- ANSI/ASME B1.20.1
- Pressure connection type
- NPT
- Pressure Male/Female
- Female
- Pressure sensing element
- Bellows
- Product accessories
- Switches accessories
- Product description
- Pressure Switch
- Product family name
- KP
- Product group
- Switches and thermostats
- Product name
- Pressure switch
- Quantity per packing format
- 36 pc
- Regulation range [bar] Pe [Max]
- 21 bar
- Regulation range [bar] Pe [Min]
- 4 bar
- Regulation range [psig] Pe [Max]
- 300 psig
- Regulation range [psig] Pe [Min]
- 58 psig
- Reset function
- Auto
- Serviceable
- No
- TYPE
- KP37
- UL approval file name
- E31024MH27572
