Артикул: 080Z0186

В наличии

Danfoss 080Z0186 - Pack controller, AK-⁠PC 781

Цена по запросу Стоимость зависит от выбранного способа оплаты и количества товара.

Подберем решение под ваши задачи
Поможем выбрать подходящий вариант, проверим совместимость и подготовим коммерческое предложение
Вы можете добавить файлы с реквизитами компании, спецификацией или ТЗ

Не отвечаем 5 минут — скидка на весь заказ!

sale@df-russia.ru

Нужна скидка? Звони — сделаем лучшее предложение

+7 495 266-67-99

Работаем по всей России

Возможны самовывоз и доставка по всей территории России

Надежность

Профессиональная поддержка

Danfoss 080Z0186 - Pack controller, AK-PC 781

Function: Pack w. Heat Reclaim, Supply voltage [V] AC: 24, Communication type: IO Extension; LON RS485; RJ45 (RS232) to PC/ Display, Packing format: Single pack, Quantity per packing format: 1

Информация о продукте

Gross weight 0.93 kg
Net weight 0.65 kg
EAN 5702428463966



Addit. thermostats inputs max. 5 pc
Addit.press.switche inputs max 5 pc
Additional alarm inputs max. 10 pc
Additional analog inputs max. 5 pc
Analog inputs (AI) [pc] 11 pc
Application area Capacity control
Approval C-TICK, CE, EAC, LLC CDC TYSK, cURus
Capacity control input Pressure/ Temperature
Capacity control mode PI
Communication type IO Extension, LON RS485, RJ45 (RS232) to PC/ Display
Compressor capacity mode Step/ Speed
Condenser control type Pressure/ Temperature
Controller type Pack Controller
Digital outputs (DO) [pc] 8 pc
Display - option AK-MMI, EKA 163B, EKA 164B, EKA 166
Display on front No
Enclosure rating IP IP10
Equipment
Fan capacity control Step/ Speed
Fan control mode PI
Frequency [Hz] 50/60 Hz
Function Pack w. Heat Reclaim
Further information Transcri.,Speed,CO2,HP,Oil,HR
I/O connectors max. 120 pc
No.of compr. safty signals max 6 pc
No.of extention modules max. 11 pc
Number of Compressors max. 8 pc
Number of fans max. 8 pc
Oil management Yes, w. CO2
Packing format Single pack
Power consumption [VA] 8 VA
Product features CO2 compliant, Condenser error monitoring, External comm. included, Floating condenser pressure, Heat recovery function, Load shedding, Night setback, P0 optimization, Pump control, Three way valve control
Product group Compressor/condenser control
Product Language Chinese, Czech, Danish, Dutch, English, Finnish, French, German, Italian, Polish, Portuguese, Russian, Spanish
Product name Pack controller
Programming tools AK-ST 500
Quantity per packing format 1 pc
Supply voltage [V] DC 24 V
Supply voltage [V] AC 24 V
Supply voltage [V] DC 24 V
Type AK-PC 781

Сайт продавца продукции Danfoss. Получить дополнительную информацию о стоимости, описании, спецификации и характеристиках вы можете по телефону +7 495 266-67-99 или электронной почте sale@df-russia.ru.

Технические характеристики 080Z0186

Основные характеристики

Addit. thermostats inputs max.
5 pc
Addit.press.switche inputs max
5 pc
Additional alarm inputs max.
10 pc
Additional analog inputs max.
5 pc
Analog inputs (AI) [pc]
11 pc
Application area
Capacity control
Approval
C-TICKCEEACLLC CDC TYSKcURus
Capacity control input
Pressure/ Temperature
Capacity control mode
PI
Communication type
IO ExtensionLON RS485RJ45 (RS232) to PC/ Display
Compressor capacity mode
Step/ Speed
Condenser control type
Pressure/ Temperature
Controller type
Pack Controller
Digital outputs (DO) [pc]
8 pc
Display - option
AK-MMIEKA 163BEKA 164BEKA 166
Display on front
No
EAN
5702428463966
Enclosure rating IP
IP10
Fan capacity control
Step/ Speed
Fan control mode
PI
Frequency [Hz]
50/60 Hz
Function
Pack w. Heat Reclaim
Further information
Transcri.,Speed,CO2,HP,Oil,HR
Gross weight
0.93 kg
I/O connectors max.
120 pc
Net weight
0.65 kg
No.of compr. safty signals max
6 pc
No.of extention modules max.
11 pc
Number of Compressors max.
8 pc
Number of fans max.
8 pc
Oil management
Yes, w. CO2
Packing format
Single pack
Power consumption [VA]
8 VA
Product features
CO2 compliantCondenser error monitoringExternal comm. includedFloating condenser pressureHeat recovery functionLoad sheddingNight setbackP0 optimizationPump controlThree way valve control
Product group
Compressor/condenser control
Product Language
ChineseCzechDanishDutchEnglishFinnishFrenchGermanItalianPolishPortugueseRussianSpanish
Product name
Pack controller
Programming tools
AK-ST 500
Quantity per packing format
1 pc
Supply voltage [V] DC
24 V
Supply voltage [V] AC
24 V
Supply voltage [V] DC
24 V
TYPE
AK-PC 781
