Артикул: 145B3036
В наличии
Danfoss 145B3036 - Akva Vita II, DHW controller name: PM
Цена по запросу Стоимость зависит от выбранного способа оплаты и количества товара.
Не отвечаем 5 минут — скидка на весь заказ!
Нужна скидка? Звони — сделаем лучшее предложение
Работаем по всей России
Возможны самовывоз и доставка по всей территории России
Надежность
Профессиональная поддержка
Danfoss 145B3036 - Akva Vita II, DHW controller name: PM
Akva Vita Low Temp S XB37H-30StS PM
Информация о продукте
| Gross weight | 23 kg |
| Net weight | 22.5 kg |
| EAN | 5702428524117 |
| Gross weight | 23 kg |
| Net weight | 22.5 kg |
| EAN | 5702428524117 |
| 0-series required | No |
| Additional information | Direct HE with differential pressure controller, Safety function, Thermostatic mixing circuit |
| Application type | DHW, HE indirect |
| Connection direction | Bottom |
| Cover option | Extra |
| DCW static pressure [bar] [Min] | 2 bar |
| Depth with cover [mm] | 200 mm |
| Depth without cover [mm] | 150 mm |
| Description | Akva Vita Low Temp S XB37H-30StS PM |
| DH connection size | 3/4" |
| DH connection type | G int. Thread |
| DH pipe size | Ø18 |
| DHW capacity [kW] | 58 kW |
| DHW circulation | Extra |
| DHW connection size | G3/4" |
| DHW connection type | G int. Thread |
| DHW Control type | Flow |
| DHW controller name | PM |
| DHW HEX type | XB37 |
| Differential pressure controller | AVPL |
| Floor heating circuit - pump brand | Wilo |
| Floor heating circuit - pump type | Wilo Yonos Para 15/6 |
| HE connection size | G3/4" |
| HE connection type | G int. Thread |
| HE pipe size | Ø18 |
| Heating circuit - control | Thermostatic valve |
| Heating control type | Thermostatic + Differential pressure |
| Height with cover [mm] | 740 mm |
| Height without cover [mm] | 616 mm |
| HEX heating alloy | AISI 316 |
| HEX heating brazing material | Stainless steel |
| HEX heating type | Brazed |
| Material Description (Short Te | Akva Vita Low Temp S XB37H-30S |
| Product group | Small Stations |
| Redan APP Diagram | No |
| Type | Akva Vita II |
| Width with cover [mm] | 600 mm |
| Width without cover [mm] | 577 mm |
| 0-series required | No |
| Additional information | Direct HE with differential pressure controller, Safety function, Thermostatic mixing circuit |
| Application type | DHW, HE indirect |
| Connection direction | Bottom |
| Cover option | Extra |
| DCW static pressure [bar] [Min] | 2 bar |
| Depth with cover [mm] | 200 mm |
| Depth without cover [mm] | 150 mm |
| Description | Akva Vita Low Temp S XB37H-30StS PM |
| DH connection size | 3/4" |
| DH connection type | G int. Thread |
| DH pipe size | Ø18 |
| DHW capacity [kW] | 58 kW |
| DHW circulation | Extra |
| DHW connection size | G3/4" |
| DHW connection type | G int. Thread |
| DHW Control type | Flow |
| DHW controller name | PM |
| DHW HEX type | XB37 |
| Differential pressure controller | AVPL |
| Floor heating circuit - pump brand | Wilo |
| Floor heating circuit - pump type | Wilo Yonos Para 15/6 |
| HE connection size | G3/4" |
| HE connection type | G int. Thread |
| HE pipe size | Ø18 |
| Heating circuit - control | Thermostatic valve |
| Heating control type | Thermostatic + Differential pressure |
| Height with cover [mm] | 740 mm |
| Height without cover [mm] | 616 mm |
| HEX heating alloy | AISI 316 |
| HEX heating brazing material | Stainless steel |
| HEX heating type | Brazed |
| Material Description (Short Te | Akva Vita Low Temp S XB37H-30S |
| Product group | Small Stations |
| Redan APP Diagram | No |
| Type | Akva Vita II |
| Width with cover [mm] | 600 mm |
| Width without cover [mm] | 577 mm |
Сайт продавца продукции Danfoss. Получить дополнительную информацию о стоимости, описании, спецификации и характеристиках вы можете по телефону +7 495 266-67-99 или электронной почте sale@df-russia.ru.
Технические характеристики 145B3036
Основные характеристики
- 0-series required
- No
- Additional information
- Direct HE with differential pressure controllerSafety functionThermostatic mixing circuit
- Application type
- DHW, HE indirect
- Connection direction
- Bottom
- Cover option
- Extra
- DCW static pressure [bar] [Min]
- 2 bar
- Depth with cover [mm]
- 200 mm
- Depth without cover [mm]
- 150 mm
- Description
- Akva Vita Low Temp S XB37H-30StS PM
- DH connection size
- 3/4"
- DH connection type
- G int. Thread
- DH pipe size
- Ø18
- DHW capacity [kW]
- 58 kW
- DHW circulation
- Extra
- DHW connection size
- G3/4"
- DHW connection type
- G int. Thread
- DHW Control type
- Flow
- DHW controller name
- PM
- DHW HEX type
- XB37
- Differential pressure controller
- AVPL
- EAN
- 5702428524117
- Floor heating circuit - pump brand
- Wilo
- Floor heating circuit - pump type
- Wilo Yonos Para 15/6
- Gross weight
- 23 kg
- HE connection size
- G3/4"
- HE connection type
- G int. Thread
- HE pipe size
- Ø18
- Heating circuit - control
- Thermostatic valve
- Heating control type
- Thermostatic + Differential pressure
- Height with cover [mm]
- 740 mm
- Height without cover [mm]
- 616 mm
- HEX heating alloy
- AISI 316
- HEX heating brazing material
- Stainless steel
- HEX heating type
- Brazed
- Material Description (Short Te
- Akva Vita Low Temp S XB37H-30S
- Net weight
- 22.5 kg
- Product group
- Small Stations
- Redan APP Diagram
- No
- TYPE
- Akva Vita II
- Width with cover [mm]
- 600 mm
- Width without cover [mm]
- 577 mm
