Артикул: 180F7023

В наличии

Danfoss 180F7023 - Energy Recovery Device, iSave 50

Цена по запросу Стоимость зависит от выбранного способа оплаты и количества товара.

Подберем решение под ваши задачи
Поможем выбрать подходящий вариант, проверим совместимость и подготовим коммерческое предложение
Вы можете добавить файлы с реквизитами компании, спецификацией или ТЗ

Не отвечаем 5 минут — скидка на весь заказ!

sale@df-russia.ru

Нужна скидка? Звони — сделаем лучшее предложение

+7 495 266-67-99

Работаем по всей России

Возможны самовывоз и доставка по всей территории России

Надежность

Профессиональная поддержка

Danfoss 180F7023 - Energy Recovery Device, iSave 50

Speed [rpm] [Min]: 525, Mounting orientation: Horizontal, Speed [rpm] [Max]: 625, HP out flow [m³/h] [Max]: 52, HP out flow [gpm] [Max]: 228

Информация о продукте

Gross weight 520.5 kg
Net weight 445.36 kg



Allowable working torque [lbf·ft] [Max] 125 lbf∙ft
Allowable working torque [Nm] [Max] 170 Nm
Ambient temperature [°C] [Max] 50 °C
Ambient temperature [°C] [Min] 0 °C
Ambient temperature [°F] [Max] 122 °F
Ambient temperature [°F] [Min] 32 °F
Base frame Stainless
Country of origin Denmark
Description iSave 50, Horizontal, IEC200L, 18.5 kW
Differential pressure HP in out [barg] [Max] 5 barg
Differential pressure HP in out [psig] [Max] 72 psig
Drain connection size [in] 1/4 in
Drain connection standard BSPP
Drain connection type BSPP
Flow [gpm] [Min] 184 gal/min
Flow [m³/h] [Min] 42 m³/h
HP inlet connection size [in] 3 in
HP Inlet connection standard Victaulic
HP inlet pressure [barg] [Min] 40 barg
HP inlet pressure [psig] [Min] 580 psig
HP inlet pressure, intermittent [barg] [Min] 2 barg
HP inlet pressure, intermittent [psig] [Min] 29 psig
HP out flow [gpm] [Max] 228 gal/min
HP out flow [m³/h] [Max] 52 m³/h
HP outlet connection size [in] 3 in
HP Outlet connection standard Victaulic
HP outlet pressure [barg] [Max] 83 barg
HP outlet pressure [psig] [Max] 1200 psig
IP protection class IP55
LP in out @ max flow [psig] 8 psig
LP in out @ max. flow [barg] 1 barg
LP in out max. static test pressure [barg] 13 barg
LP in out max. static test pressure [psig] 189 psig
LP inlet allowable working flow [gpm] [Max] 252 gal/min
LP inlet allowable working flow [m³/h] [Max] 57 m³/h
LP Inlet allowable working pressure [barg] [Min] 2 barg
LP Inlet allowable working pressure [psig] [Min] 29 psig
LP inlet connection size [in] 3 in
LP Inlet connection standard Victaulic
LP inlet pressure [barg] [Max] 5 barg
LP inlet pressure [psig] [Max] 72 psig
LP Inlet pressure peak [barg] 10 barg
LP Inlet pressure peak [psig] 145 barg
LP outlet connection size [in] 3 in
Lubrication flow at 60 [m³/h] [Max] 1.5 m³/h
Lubrication flow at 871 [gpm] [Max] 6.6 gal/min
Material type Duplex, Super Duplex
Media temperature [°C] [Max] 35 °C
Media temperature [°C] [Min] 2 °C
Media temperature [°F] [Max] 95 °F
Media temperature [°F] [Min] 36 °F
Motor ambient temperature [°C] [Max] 40 °C
Motor ambient temperature [°F] [Max] 104 °F
Motor current [A] 37 A
Motor frame Size 200L
Motor insulation class B
Motor poles 6
Motor standard IEC
Motor Torque at nom. speed [lbf·ft] 130.5 lbf∙ft
Motor torque at nom. speed [Nm] 177 Nm
Motor voltage 380-420V/660720V, 50 Hz, 440-480V, 60 Hz
Mounting orientation Horizontal
Outside dimensions of packaging LxWxH [in] 74,8x24,4x32,1
Outside dimensions of packaging LxWxH [mm] 1907x622x819
Product group Energy Recovery Device
Product name iSave
Rated power [HP] 30 hp
Rated power [kW] 18.5 kW
Seal Material NBR
Serviceable Yes
Sound pressure level [dB(A)] 83 dBA
Speed [rpm] [Max] 625 rpm
Speed [rpm] [Min] 525 rpm
Starting torque [lbf·ft] [Max] 132 lbf∙ft
Starting torque [Nm] [Max] 180 Nm
Static test pressure HP in out [barg] [Max] 108 barg
Static test pressure HP in out [psig] [Max] 1566 psig
Type iSave 50-70
Type designation iSave 50

Сайт продавца продукции Danfoss. Получить дополнительную информацию о стоимости, описании, спецификации и характеристиках вы можете по телефону +7 495 266-67-99 или электронной почте sale@df-russia.ru.

Технические характеристики 180F7023

Основные характеристики

Allowable working torque [lbf·ft] [Max]
125 lbf∙ft
Allowable working torque [Nm] [Max]
170 Nm
Ambient temperature [°C] [Max]
50 °C
Ambient temperature [°C] [Min]
0 °C
Ambient temperature [°F] [Max]
122 °F
Ambient temperature [°F] [Min]
32 °F
Base frame
Stainless
Country of origin
Denmark
Description
iSave 50, Horizontal, IEC200L, 18.5 kW
Differential pressure HP in out [barg] [Max]
5 barg
Differential pressure HP in out [psig] [Max]
72 psig
Drain connection size [in]
1/4 in
Drain connection standard
BSPP
Drain connection type
BSPP
Flow [gpm] [Min]
184 gal/min
Flow [m³/h] [Min]
42 m³/h
Gross weight
520.5 kg
HP inlet connection size [in]
3 in
HP Inlet connection standard
Victaulic
HP inlet pressure [barg] [Min]
40 barg
HP inlet pressure [psig] [Min]
580 psig
HP inlet pressure, intermittent [barg] [Min]
2 barg
HP inlet pressure, intermittent [psig] [Min]
29 psig
HP out flow [gpm] [Max]
228 gal/min
HP out flow [m³/h] [Max]
52 m³/h
HP outlet connection size [in]
3 in
HP Outlet connection standard
Victaulic
HP outlet pressure [barg] [Max]
83 barg
HP outlet pressure [psig] [Max]
1200 psig
IP protection class
IP55
LP in out @ max flow [psig]
8 psig
LP in out @ max. flow [barg]
1 barg
LP in out max. static test pressure [barg]
13 barg
LP in out max. static test pressure [psig]
189 psig
LP inlet allowable working flow [gpm] [Max]
252 gal/min
LP inlet allowable working flow [m³/h] [Max]
57 m³/h
LP Inlet allowable working pressure [barg] [Min]
2 barg
LP Inlet allowable working pressure [psig] [Min]
29 psig
LP inlet connection size [in]
3 in
LP Inlet connection standard
Victaulic
LP Inlet pressure peak [barg]
10 barg
LP Inlet pressure peak [psig]
145 barg
LP inlet pressure [barg] [Max]
5 barg
LP inlet pressure [psig] [Max]
72 psig
LP outlet connection size [in]
3 in
Lubrication flow at 60 [m³/h] [Max]
1.5 m³/h
Lubrication flow at 871 [gpm] [Max]
6.6 gal/min
Material type
DuplexSuper Duplex
Media temperature [°C] [Max]
35 °C
Media temperature [°C] [Min]
2 °C
Media temperature [°F] [Max]
95 °F
Media temperature [°F] [Min]
36 °F
Motor ambient temperature [°C] [Max]
40 °C
Motor ambient temperature [°F] [Max]
104 °F
Motor current [A]
37 A
Motor frame Size
200L
Motor insulation class
B
Motor poles
6
Motor standard
IEC
Motor Torque at nom. speed [lbf·ft]
130.5 lbf∙ft
Motor torque at nom. speed [Nm]
177 Nm
Motor voltage
380-420V/660720V, 50 Hz440-480V, 60 Hz
Mounting orientation
Horizontal
Net weight
445.36 kg
Outside dimensions of packaging LxWxH [in]
74,8x24,4x32,1
Outside dimensions of packaging LxWxH [mm]
1907x622x819
Product group
Energy Recovery Device
Product name
iSave
Rated power [HP]
30 hp
Rated power [kW]
18.5 kW
Seal Material
NBR
Serviceable
Yes
Sound pressure level [dB(A)]
83 dBA
Speed [rpm] [Max]
625 rpm
Speed [rpm] [Min]
525 rpm
Starting torque [lbf·ft] [Max]
132 lbf∙ft
Starting torque [Nm] [Max]
180 Nm
Static test pressure HP in out [barg] [Max]
108 barg
Static test pressure HP in out [psig] [Max]
1566 psig
TYPE
iSave 50-70
Type designation
iSave 50
